Tekin RX8 GEN3 1/8 Competition Brushless ESC
Information
Tekin's RX8 GEN3 brings bigger power handling capabilities and increased reliability to 1/8 Scale Racing. The RX8 platform has proven itself to handle the rigors of racing, while providing professional features including a programmable High Voltage BEC, Data Logging Capabilities, Timing Profiles, Voltage Cutoffs for LiPos, HotWire 3.0 Bluetooth Connectivity and more. Utilizing Tekin's D2 Dual Drive Mode Technology, the RX8 runs both Sensored and Sensorless motor drives seamlessly, giving you the best of both worlds. The small footprint makes install on any chassis easy with the option of mounting with included hardware for extra security. Combo the RX8 GEN3 with a Tekin T8 Brushless Motor for 1/8 Scale Buggies and Truggies or a Pro4HD for 4WD Short Course domination!
Features
Bluetooth Wirless Mobile and USB PC Tuning with the HotWire 3.0 New HD Gold-plated Solder Posts for Easy Soldering
Multi-Fin High Efficiency Heat Sink and Optional High RPM Cooling Fan 3rd Channel Input for On-The-Fly Drag Brake Adjustments <<setup>>
QuickTune™ One Touch Programming Adjustable Torque Control * Adjustable Throttle and Brake Frequencies *
HD High Voltage Programmable BEC * HotWire™ Programming Port * Data Logging Capability * Sensor Checker On-Board Temperature Indicator
ESC Self Diagnostics with Error Codes Fully Proportional Forward/Brake/Reverse
Brushless and Brushed Motor Drive
Sensored or Sensorless Operation
LiPo Safe with Custom Voltage Cutoffs
Sensor Plug for Precise Commutation
HDAC: High Density Copper PCB's Ultra-smooth and Precise Throttle and Braking Control
* requires HotWire™ sold separately.
ON BOARD QuickTune™ PROGRAMMABLE FEATURES DB - Drag Brake (13 steps)
BS - Brake Strength (13 steps)
LM - Torque Limiter (7 steps)
NW - Neutral Width (13 steps)
TP - Timing Profiles 5 Preset - 2 Custom*
MT - Motor Type
Brushless Modes - FWD Only / FWD-REV / FWD-REV Delay /
FWD-REV Delay REV Motor Direction
Brushed Modes - FWD Only / FWD-REV / FWD-REV Delay
VC - Voltage Cutoff : 2S, 3S, 4S, 5S, 6S, Custom*
* requires HotWire™ sold separately.
Specifications
Controls: Forward/Brake/Reverse
Input Voltage: 2S-6S LiPo / 4-16S NiMH-NiCD
Motor Limit Brushless Mode: 2S - No Limit
3S - 4000kV
4S - 3500kV
5S - 2000kV
6S - 1700kV
Motor Limit Brushed Mode: No Limit
Max Current: 300amps per phase*
Burst Current: 1000amps per phase*
BEC: 6.0v / 7.4v @ 8amps
Dimensions: 1.5 x 2.2 x 1.4" / 38 x 55.8 x 35.5mm
Weight: 2.7oz / 76.5g
*per manufacturer spec
OFF ROAD
1:10 4WD Short Course
1:8 4WD Buggy
1:8 4WD Truggy
1:8 4WD Monster Truck
ON ROAD
1:8 4WD Touring Car
1:8 4WD GP Car
OVAL
1:10 4WD SC Modified
1:8 4WD Late Model
